Smooth Value Modifier
Updated: 20 Aug 2025
Smooths incoming modifier values.
Smooth Value Modifier
Method #
This node smooths incoming modifier values over time to create a smoother output value. Useful for removing noise and smoothing data from some sources, or creating envelopes from triggers.
The output is a numeric value that can be further processed with other modifiers, or directly connected to a parameter in another node, using the operation method selected.
Parameters
These properties control the core behaviours of the node.
Parameter Details Current Value
Shows the current value of the effect. Cannot be directly changed.
Value
Base value to modify the output value with.
Scale
Adjust the scale/range of the modifier.
Attack
Controls the initial time between the current value to the peak.
Decay
Controls the time between the peak to the sustain level.
Hard Change Threshold
If the value goes above this threshold, hard jump without smoothing.
Operation
The operation to be performed on the targeted parameter.
- Add : Adds to the parameter value.
- Subtract : Subtracts from the parameter value.
- Multiply : Multiplies the parameter value.
- Replace : Replaces the parameter value.
Restore Values
Attempt to move back to the current value to the input value more quickly.
The properties control the time at which the node is active. See Timeline for editing time segments.
Parameter Details Duration
Control the duration of the node’s time segment.
- Composition Duration : Use the length of the composition for the node’s time segment duration.
- Custom : Set a custom duration for the node’s time segment.
Node Time
The custom start and end time for the node.
Duration (Timecode)
The length of the node’s time segment (in time).
Duration (Frames)
The length of the node’s time segment (in frames).
Time Segment Enabled
Set whether the node’s time segment is enabled or not in the Timeline.
Inputs
These properties control the core behaviours of the node.
| Parameter | Details |
|---|---|
| Current Value | Shows the current value of the effect. Cannot be directly changed. |
| Value | Base value to modify the output value with. |
| Scale | Adjust the scale/range of the modifier. |
| Attack | Controls the initial time between the current value to the peak. |
| Decay | Controls the time between the peak to the sustain level. |
| Hard Change Threshold | If the value goes above this threshold, hard jump without smoothing. |
| Operation |
The operation to be performed on the targeted parameter.
|
| Restore Values | Attempt to move back to the current value to the input value more quickly. |
The properties control the time at which the node is active. See Timeline for editing time segments.
| Parameter | Details |
|---|---|
| Duration |
Control the duration of the node’s time segment.
|
| Node Time | The custom start and end time for the node. |
| Duration (Timecode) | The length of the node’s time segment (in time). |
| Duration (Frames) | The length of the node’s time segment (in frames). |
| Time Segment Enabled | Set whether the node’s time segment is enabled or not in the Timeline. |
| Name | Description | Typical Input |
|---|---|---|
| Value | Input a value from another modifier to be modified by this node. | Math Modifier |
