RGB Distortion

RGB Distortion

Updated: 24 Feb 2025

Add RGB sine distortion to an image.


Example .dfx

Method #

This node applies multiple sine waves to distort the image, each corresponding to an RGB channel. The result is then further distorted with noise, to get a convincing distortion effect. Useful as a part of a digital glitch effect, simulating the RGB channels misaligning in a CRT display.

Parameters

These properties control the core behaviours of the node.

ParameterDetails
Active Enables or disables the effect. Disabling the effect means it will no longer compute, so disabling a node when not in use can improve performance.
Blend Amount Changes the opacity of the new effect over the original image.
Blend Mode (RGB) Change how the generated effect blends with the parent image RGB.
Blend Mode (Alpha) Change how the generated effect blends with the parent image alpha.
Amount How strong an effect will be applied to the image.
Red Distribution Distribution of red distortion.
Green Distribution Distribution of green distortion.
Blue Distribution Distribution of blue distortion.
Distort Y Distortion on the y-axis.
Sine Scale Scale of the sine wave.
Noise Scale Scale of the noise.
Speed Speed at which the distortion is animated.

Toggle which of the RGBA channels are affected by the effect.

Inputs

NameDescriptionTypical Input
Mask ImageUse a mask image to control where the output is most or least affected by the effect, based on the mask images luminance.Image Plane
ActiveEnables or disables the effect. Disabling the effect means it will no longer compute, so disabling a node when not in use can improve performance.Value
